RAB ALEDXL5TB/480/WS2 Type V LED Area Light – 300W-385W Selectable – 5000K – 39963-49583 Lumens – 480V – Pole Mount – WattStopper Sensor with 20ft Lens – Black Finish

RAB ALEDXL5TB/480/WS2 Type V LED Area Light – 300W-385W Selectable – 5000K – 39963-49583 Lumens – 480V – Pole Mount – WattStopper Sensor with 20ft Lens – Black Finish

$1,936.00
$1,936.00
Skip to product information
RAB ALEDXL5TB/480/WS2 Type V LED Area Light – 300W-385W Selectable – 5000K – 39963-49583 Lumens – 480V – Pole Mount – WattStopper Sensor with 20ft Lens – Black Finish
  • RAB ALEDXL5TB/480/WS2 Type V LED Area Light – 300W-385W Selectable – 5000K – 39963-49583 Lumens – 480V – Pole Mount – WattStopper Sensor with 20ft Lens – Black Finish
  • RAB ALEDXL5TB/480/WS2 Type V LED Area Light – 300W-385W Selectable – 5000K – 39963-49583 Lumens – 480V – Pole Mount – WattStopper Sensor with 20ft Lens – Black Finish
  • RAB ALEDXL5TB/480/WS2 Type V LED Area Light – 300W-385W Selectable – 5000K – 39963-49583 Lumens – 480V – Pole Mount – WattStopper Sensor with 20ft Lens – Black Finish
  • RAB ALEDXL5TB/480/WS2 Type V LED Area Light – 300W-385W Selectable – 5000K – 39963-49583 Lumens – 480V – Pole Mount – WattStopper Sensor with 20ft Lens – Black Finish
  • RAB ALEDXL5TB/480/WS2 Type V LED Area Light – 300W-385W Selectable – 5000K – 39963-49583 Lumens – 480V – Pole Mount – WattStopper Sensor with 20ft Lens – Black Finish
  • RAB ALEDXL5TB/480/WS2 Type V LED Area Light – 300W-385W Selectable – 5000K – 39963-49583 Lumens – 480V – Pole Mount – WattStopper Sensor with 20ft Lens – Black Finish
  • RAB ALEDXL5TB/480/WS2 Type V LED Area Light – 300W-385W Selectable – 5000K – 39963-49583 Lumens – 480V – Pole Mount – WattStopper Sensor with 20ft Lens – Black Finish
  • RAB ALEDXL5TB/480/WS2 Type V LED Area Light – 300W-385W Selectable – 5000K – 39963-49583 Lumens – 480V – Pole Mount – WattStopper Sensor with 20ft Lens – Black Finish
  • RAB ALEDXL5TB/480/WS2 Type V LED Area Light – 300W-385W Selectable – 5000K – 39963-49583 Lumens – 480V – Pole Mount – WattStopper Sensor with 20ft Lens – Black Finish
  • RAB ALEDXL5TB/480/WS2 Type V LED Area Light – 300W-385W Selectable – 5000K – 39963-49583 Lumens – 480V – Pole Mount – WattStopper Sensor with 20ft Lens – Black Finish
  • RAB ALEDXL5TB/480/WS2 Type V LED Area Light – 300W-385W Selectable – 5000K – 39963-49583 Lumens – 480V – Pole Mount – WattStopper Sensor with 20ft Lens – Black Finish
  • RAB ALEDXL5TB/480/WS2 Type V LED Area Light – 300W-385W Selectable – 5000K – 39963-49583 Lumens – 480V – Pole Mount – WattStopper Sensor with 20ft Lens – Black Finish
  • RAB ALEDXL5TB/480/WS2 Type V LED Area Light – 300W-385W Selectable – 5000K – 39963-49583 Lumens – 480V – Pole Mount – WattStopper Sensor with 20ft Lens – Black Finish
  • RAB ALEDXL5TB/480/WS2 Type V LED Area Light – 300W-385W Selectable – 5000K – 39963-49583 Lumens – 480V – Pole Mount – WattStopper Sensor with 20ft Lens – Black Finish
  • RAB ALEDXL5TB/480/WS2 Type V LED Area Light – 300W-385W Selectable – 5000K – 39963-49583 Lumens – 480V – Pole Mount – WattStopper Sensor with 20ft Lens – Black Finish
  • RAB ALEDXL5TB/480/WS2 Type V LED Area Light – 300W-385W Selectable – 5000K – 39963-49583 Lumens – 480V – Pole Mount – WattStopper Sensor with 20ft Lens – Black Finish
  • RAB ALEDXL5TB/480/WS2 Type V LED Area Light – 300W-385W Selectable – 5000K – 39963-49583 Lumens – 480V – Pole Mount – WattStopper Sensor with 20ft Lens – Black Finish
  • RAB ALEDXL5TB/480/WS2 Type V LED Area Light – 300W-385W Selectable – 5000K – 39963-49583 Lumens – 480V – Pole Mount – WattStopper Sensor with 20ft Lens – Black Finish
RAB ALEDXL5TB/480/WS2 Type V LED Area Light – 300W-385W Selectable – 5000K – 39963-49583 Lumens – 480V – Pole Mount – WattStopper Sensor with 20ft Lens – Black Finish

RAB ALEDXL5TB/480/WS2 Type V LED Area Light – 300W-385W Selectable – 5000K – 39963-49583 Lumens – 480V – Pole Mount – WattStopper Sensor with 20ft Lens – Black Finish

UL Certified DLC Premium Listed Wattage Adjustable Type V Distribution Multi-Level Motion Sensor IP66 Rating 0-10V Dimmable 10kV Surge Protection Wet Location Rated 80+ CRI 480V 100000 Rated Hours

Description

The RAB Lighting ALEDXL5TB/480/WS2 LED pole-mount area light is configured with selectable 300W-385W operation, 39963-49583 lumens, and 5000K color temperature. It features Type V light distribution, pole mount, 480V input, WattStopper Sensor with 20ft Lens, and black finish. This area light is suited for open parking and general area-lighting layouts that require broad, symmetrical coverage and is designed for fixed installation on compatible area-light poles or mounting arms.

Specifications

  • Vendor: RAB Lighting
  • MPN: ALEDXL5TB/480/WS2
  • Product Type: Area Light
  • Wattage: 300W, 345W, 385W
  • Input Voltage: 480V
  • Lumens: 39963-49583
  • CCT: 5000K
  • CRI: 80+
  • Light Distribution: Type V
  • Dimming: 0-10V
  • Features: Wattage Selectable, CCT Selectable, Multi-Level Motion Sensor with 20' Lens
  • Certifications: UL
  • DLC Rating: DLC Premium
  • DLC Product ID: S-8KMW34
  • IP Rating: IP66
  • Location Rating: Wet
  • Mounting Type: Pole
  • Mounting Height: 25–35 ft
  • Housing: Die-Cast Aluminum
  • Lens: Polycarbonate
  • Operating Temperature: -40°F to 104°F (-40°C to 40°C)
  • Weight: 34.5 lbs
  • Finish: Black
  • Dimensions: 32.625"L x 19"W x 6.375"H
  • Rated Hours: 100000
  • Warranty: 10 Years
  • Applications: Parking Lots, Roadways, Commercial Campuses, Distribution Centers, Industrial Facilities
