RAB ALEDL4TWMNW/7PR Type IV LED Area Light – 170W-260W Selectable – 4000K – 24929-36872 Lumens – 120-277V – Wall Mount – NEMA 7-Pin Photocontrol Receptacle – White Finish

RAB ALEDL4TWMNW/7PR Type IV LED Area Light – 170W-260W Selectable – 4000K – 24929-36872 Lumens – 120-277V – Wall Mount – NEMA 7-Pin Photocontrol Receptacle – White Finish

$1,512.00
$1,512.00
Skip to product information
RAB ALEDL4TWMNW/7PR Type IV LED Area Light – 170W-260W Selectable – 4000K – 24929-36872 Lumens – 120-277V – Wall Mount – NEMA 7-Pin Photocontrol Receptacle – White Finish
  • RAB ALEDL4TWMNW/7PR Type IV LED Area Light – 170W-260W Selectable – 4000K – 24929-36872 Lumens – 120-277V – Wall Mount – NEMA 7-Pin Photocontrol Receptacle – White Finish
  • RAB ALEDL4TWMNW/7PR Type IV LED Area Light – 170W-260W Selectable – 4000K – 24929-36872 Lumens – 120-277V – Wall Mount – NEMA 7-Pin Photocontrol Receptacle – White Finish
  • RAB ALEDL4TWMNW/7PR Type IV LED Area Light – 170W-260W Selectable – 4000K – 24929-36872 Lumens – 120-277V – Wall Mount – NEMA 7-Pin Photocontrol Receptacle – White Finish
  • RAB ALEDL4TWMNW/7PR Type IV LED Area Light – 170W-260W Selectable – 4000K – 24929-36872 Lumens – 120-277V – Wall Mount – NEMA 7-Pin Photocontrol Receptacle – White Finish
  • RAB ALEDL4TWMNW/7PR Type IV LED Area Light – 170W-260W Selectable – 4000K – 24929-36872 Lumens – 120-277V – Wall Mount – NEMA 7-Pin Photocontrol Receptacle – White Finish
  • RAB ALEDL4TWMNW/7PR Type IV LED Area Light – 170W-260W Selectable – 4000K – 24929-36872 Lumens – 120-277V – Wall Mount – NEMA 7-Pin Photocontrol Receptacle – White Finish
  • RAB ALEDL4TWMNW/7PR Type IV LED Area Light – 170W-260W Selectable – 4000K – 24929-36872 Lumens – 120-277V – Wall Mount – NEMA 7-Pin Photocontrol Receptacle – White Finish
  • RAB ALEDL4TWMNW/7PR Type IV LED Area Light – 170W-260W Selectable – 4000K – 24929-36872 Lumens – 120-277V – Wall Mount – NEMA 7-Pin Photocontrol Receptacle – White Finish
  • RAB ALEDL4TWMNW/7PR Type IV LED Area Light – 170W-260W Selectable – 4000K – 24929-36872 Lumens – 120-277V – Wall Mount – NEMA 7-Pin Photocontrol Receptacle – White Finish
  • RAB ALEDL4TWMNW/7PR Type IV LED Area Light – 170W-260W Selectable – 4000K – 24929-36872 Lumens – 120-277V – Wall Mount – NEMA 7-Pin Photocontrol Receptacle – White Finish
  • RAB ALEDL4TWMNW/7PR Type IV LED Area Light – 170W-260W Selectable – 4000K – 24929-36872 Lumens – 120-277V – Wall Mount – NEMA 7-Pin Photocontrol Receptacle – White Finish
  • RAB ALEDL4TWMNW/7PR Type IV LED Area Light – 170W-260W Selectable – 4000K – 24929-36872 Lumens – 120-277V – Wall Mount – NEMA 7-Pin Photocontrol Receptacle – White Finish
  • RAB ALEDL4TWMNW/7PR Type IV LED Area Light – 170W-260W Selectable – 4000K – 24929-36872 Lumens – 120-277V – Wall Mount – NEMA 7-Pin Photocontrol Receptacle – White Finish
  • RAB ALEDL4TWMNW/7PR Type IV LED Area Light – 170W-260W Selectable – 4000K – 24929-36872 Lumens – 120-277V – Wall Mount – NEMA 7-Pin Photocontrol Receptacle – White Finish
  • RAB ALEDL4TWMNW/7PR Type IV LED Area Light – 170W-260W Selectable – 4000K – 24929-36872 Lumens – 120-277V – Wall Mount – NEMA 7-Pin Photocontrol Receptacle – White Finish
  • RAB ALEDL4TWMNW/7PR Type IV LED Area Light – 170W-260W Selectable – 4000K – 24929-36872 Lumens – 120-277V – Wall Mount – NEMA 7-Pin Photocontrol Receptacle – White Finish
  • RAB ALEDL4TWMNW/7PR Type IV LED Area Light – 170W-260W Selectable – 4000K – 24929-36872 Lumens – 120-277V – Wall Mount – NEMA 7-Pin Photocontrol Receptacle – White Finish
  • RAB ALEDL4TWMNW/7PR Type IV LED Area Light – 170W-260W Selectable – 4000K – 24929-36872 Lumens – 120-277V – Wall Mount – NEMA 7-Pin Photocontrol Receptacle – White Finish
RAB ALEDL4TWMNW/7PR Type IV LED Area Light – 170W-260W Selectable – 4000K – 24929-36872 Lumens – 120-277V – Wall Mount – NEMA 7-Pin Photocontrol Receptacle – White Finish

RAB ALEDL4TWMNW/7PR Type IV LED Area Light – 170W-260W Selectable – 4000K – 24929-36872 Lumens – 120-277V – Wall Mount – NEMA 7-Pin Photocontrol Receptacle – White Finish

UL Certified DLC Premium Listed Wattage Adjustable Type IV Distribution 7-Pin Receptacle IP66 Rating 0-10V Dimmable 10kV Surge Protection Wet Location Rated 80+ CRI 120-277V 100000 Rated Hours

Description

The RAB Lighting ALEDL4TWMNW/7PR LED wall-mount area light is configured with selectable 170W-260W operation, 24929-36872 lumens, and 4000K color temperature. It features Type IV light distribution, wall mount, 120-277V input, NEMA 7-Pin Photocontrol Receptacle, and white finish. This area light is suited for building perimeters and lot edges where illumination is directed outward from the mounting line and is designed for perimeter installation on a compatible wall-mounted arm or bracket.

Specifications

  • Vendor: RAB Lighting
  • MPN: ALEDL4TWMNW/7PR
  • Product Type: Area Light
  • Wattage: 170W, 220W, 260W
  • Input Voltage: 120-277V
  • Lumens: 24929-36872
  • CCT: 4000K
  • CRI: 80+
  • Light Distribution: Type IV
  • Dimming: 0-10V
  • Features: Wattage Selectable, CCT Selectable, 7-Pin Receptacle
  • Certifications: UL
  • DLC Rating: DLC Premium
  • DLC Product ID: S-1IYOH7
  • IP Rating: IP66
  • Location Rating: Wet
  • Mounting Type: Wall
  • Mounting Height: 25–35 ft
  • Housing: Die-Cast Aluminum
  • Lens: Polycarbonate
  • Operating Temperature: -40°F to 104°F (-40°C to 40°C)
  • Weight: 26.4 lbs
  • Finish: White
  • Dimensions: 28.875"L x 17.25"W x 5"H
  • Rated Hours: 100000
  • Warranty: 10 Years
  • Applications: Parking Lots, Roadways, Commercial Campuses, Distribution Centers, Industrial Facilities
$1,512.00
$1,512.00
In Stock
Free Standard Shipping: Available on all RAB Lighting products.
Lead Time: 1–3 Business Days

Payment & Security

American Express Apple Pay Discover Google Pay Mastercard PayPal Shop Pay Visa

Trusted by contractors, businesses, and facility managers since 1996.

Commercial Lighting Supply BBB Accredited Business

Project Support & Volume Pricing

Need help choosing the right product or pricing a larger order? Our team can assist with specifications, compatibility, fixture schedules, controls packages, contractor pricing, and bulk quantity quotes.

Request a Quote Need Help Choosing?
Shipping

Fast and reliable shipping from leading commercial lighting manufacturers. Shipping rates and delivery options are calculated at checkout. Most in-stock products ship within 1–3 business days.


View Shipping Policy →
Return policy

Purchase with confidence. Eligible products may be returned within 60 days of receipt. Our team is available to assist with returns, replacements, and manufacturer warranty support.


View Return Policy →

Downloads

📖 Product Brochure ↓ Specification Sheet ⧉ Family Specification Sheet ◈ LM79 Report ◫ IES File ⚙ Installation Instructions ↗ View Warranty Information
