RAB ALEDSATNW Type AT LED Area Light – 40W-80W Selectable – 4000K – 5746-10637 Lumens – 120-277V – Pole Mount – White Finish

RAB ALEDSATNW Type AT LED Area Light – 40W-80W Selectable – 4000K – 5746-10637 Lumens – 120-277V – Pole Mount – White Finish

$680.00
$680.00
Skip to product information
RAB ALEDSATNW Type AT LED Area Light – 40W-80W Selectable – 4000K – 5746-10637 Lumens – 120-277V – Pole Mount – White Finish
  • RAB ALEDSATNW Type AT LED Area Light – 40W-80W Selectable – 4000K – 5746-10637 Lumens – 120-277V – Pole Mount – White Finish
  • RAB ALEDSATNW Type AT LED Area Light – 40W-80W Selectable – 4000K – 5746-10637 Lumens – 120-277V – Pole Mount – White Finish
  • RAB ALEDSATNW Type AT LED Area Light – 40W-80W Selectable – 4000K – 5746-10637 Lumens – 120-277V – Pole Mount – White Finish
  • RAB ALEDSATNW Type AT LED Area Light – 40W-80W Selectable – 4000K – 5746-10637 Lumens – 120-277V – Pole Mount – White Finish
  • RAB ALEDSATNW Type AT LED Area Light – 40W-80W Selectable – 4000K – 5746-10637 Lumens – 120-277V – Pole Mount – White Finish
  • RAB ALEDSATNW Type AT LED Area Light – 40W-80W Selectable – 4000K – 5746-10637 Lumens – 120-277V – Pole Mount – White Finish
  • RAB ALEDSATNW Type AT LED Area Light – 40W-80W Selectable – 4000K – 5746-10637 Lumens – 120-277V – Pole Mount – White Finish
  • RAB ALEDSATNW Type AT LED Area Light – 40W-80W Selectable – 4000K – 5746-10637 Lumens – 120-277V – Pole Mount – White Finish
  • RAB ALEDSATNW Type AT LED Area Light – 40W-80W Selectable – 4000K – 5746-10637 Lumens – 120-277V – Pole Mount – White Finish
  • RAB ALEDSATNW Type AT LED Area Light – 40W-80W Selectable – 4000K – 5746-10637 Lumens – 120-277V – Pole Mount – White Finish
  • RAB ALEDSATNW Type AT LED Area Light – 40W-80W Selectable – 4000K – 5746-10637 Lumens – 120-277V – Pole Mount – White Finish
  • RAB ALEDSATNW Type AT LED Area Light – 40W-80W Selectable – 4000K – 5746-10637 Lumens – 120-277V – Pole Mount – White Finish
  • RAB ALEDSATNW Type AT LED Area Light – 40W-80W Selectable – 4000K – 5746-10637 Lumens – 120-277V – Pole Mount – White Finish
  • RAB ALEDSATNW Type AT LED Area Light – 40W-80W Selectable – 4000K – 5746-10637 Lumens – 120-277V – Pole Mount – White Finish
  • RAB ALEDSATNW Type AT LED Area Light – 40W-80W Selectable – 4000K – 5746-10637 Lumens – 120-277V – Pole Mount – White Finish
  • RAB ALEDSATNW Type AT LED Area Light – 40W-80W Selectable – 4000K – 5746-10637 Lumens – 120-277V – Pole Mount – White Finish
  • RAB ALEDSATNW Type AT LED Area Light – 40W-80W Selectable – 4000K – 5746-10637 Lumens – 120-277V – Pole Mount – White Finish
  • RAB ALEDSATNW Type AT LED Area Light – 40W-80W Selectable – 4000K – 5746-10637 Lumens – 120-277V – Pole Mount – White Finish
RAB ALEDSATNW Type AT LED Area Light – 40W-80W Selectable – 4000K – 5746-10637 Lumens – 120-277V – Pole Mount – White Finish

RAB ALEDSATNW Type AT LED Area Light – 40W-80W Selectable – 4000K – 5746-10637 Lumens – 120-277V – Pole Mount – White Finish

UL Certified DLC Premium Listed Wattage Adjustable Type AT Automotive Dealership Optics IP66 Rating 0-10V Dimmable 10kV Surge Protection Wet Location Rated 80+ CRI 120-277V 100000 Rated Hours

Description

The RAB Lighting ALEDSATNW LED pole-mount area light is configured with selectable 40W-80W operation, 5746-10637 lumens, and 4000K color temperature. It features Type AT optics, pole mounting, and 120-277V operation in a white housing. This area light is suited for automotive and parking-area layouts designed around an asymmetric forward-throw pattern and is designed for fixed installation on compatible area-light poles or mounting arms. Selectable wattage allows light output to be adjusted during installation to meet project requirements.

Specifications

  • Vendor: RAB Lighting
  • MPN: ALEDSATNW
  • Product Type: Area Light
  • Wattage: 40W, 60W, 80W
  • Input Voltage: 120-277V
  • Lumens: 5746-10637
  • CCT: 4000K
  • CRI: 80+
  • Light Distribution: Auto Dealership Optic
  • Dimming: 0-10V
  • Features: Wattage Selectable, CCT Selectable
  • Certifications: UL
  • DLC Rating: DLC Premium
  • DLC Product ID: S-O4TPAC
  • IP Rating: IP66
  • Location Rating: Wet
  • Mounting Type: Pole
  • Mounting Height: 15–20 ft
  • Housing: Die-Cast Aluminum
  • Lens: Polycarbonate
  • Operating Temperature: -40°F to 104°F (-40°C to 40°C)
  • Weight: 13.2 lbs
  • Finish: White
  • Dimensions: 21.0625"L x 10.9625"W x 5.75"H
  • Rated Hours: 100000
  • Warranty: 10 Years
  • Applications: Parking Lots, Roadways, Commercial Campuses, Distribution Centers, Industrial Facilities
$680.00
$680.00
In Stock
Free Standard Shipping: Available on all RAB Lighting products.
Lead Time: 1–3 Business Days
