RAB ALEDXL5TWMNB/480 Type V LED Area Light – 300W-385W Selectable – 4000K – 39482-48439 Lumens – 480V – Wall Mount – Black Finish

RAB ALEDXL5TWMNB/480 Type V LED Area Light – 300W-385W Selectable – 4000K – 39482-48439 Lumens – 480V – Wall Mount – Black Finish

$1,775.00
$1,775.00
Skip to product information
RAB ALEDXL5TWMNB/480 Type V LED Area Light – 300W-385W Selectable – 4000K – 39482-48439 Lumens – 480V – Wall Mount – Black Finish
  • RAB ALEDXL5TWMNB/480 Type V LED Area Light – 300W-385W Selectable – 4000K – 39482-48439 Lumens – 480V – Wall Mount – Black Finish
  • RAB ALEDXL5TWMNB/480 Type V LED Area Light – 300W-385W Selectable – 4000K – 39482-48439 Lumens – 480V – Wall Mount – Black Finish
  • RAB ALEDXL5TWMNB/480 Type V LED Area Light – 300W-385W Selectable – 4000K – 39482-48439 Lumens – 480V – Wall Mount – Black Finish
  • RAB ALEDXL5TWMNB/480 Type V LED Area Light – 300W-385W Selectable – 4000K – 39482-48439 Lumens – 480V – Wall Mount – Black Finish
  • RAB ALEDXL5TWMNB/480 Type V LED Area Light – 300W-385W Selectable – 4000K – 39482-48439 Lumens – 480V – Wall Mount – Black Finish
  • RAB ALEDXL5TWMNB/480 Type V LED Area Light – 300W-385W Selectable – 4000K – 39482-48439 Lumens – 480V – Wall Mount – Black Finish
  • RAB ALEDXL5TWMNB/480 Type V LED Area Light – 300W-385W Selectable – 4000K – 39482-48439 Lumens – 480V – Wall Mount – Black Finish
  • RAB ALEDXL5TWMNB/480 Type V LED Area Light – 300W-385W Selectable – 4000K – 39482-48439 Lumens – 480V – Wall Mount – Black Finish
  • RAB ALEDXL5TWMNB/480 Type V LED Area Light – 300W-385W Selectable – 4000K – 39482-48439 Lumens – 480V – Wall Mount – Black Finish
  • RAB ALEDXL5TWMNB/480 Type V LED Area Light – 300W-385W Selectable – 4000K – 39482-48439 Lumens – 480V – Wall Mount – Black Finish
  • RAB ALEDXL5TWMNB/480 Type V LED Area Light – 300W-385W Selectable – 4000K – 39482-48439 Lumens – 480V – Wall Mount – Black Finish
  • RAB ALEDXL5TWMNB/480 Type V LED Area Light – 300W-385W Selectable – 4000K – 39482-48439 Lumens – 480V – Wall Mount – Black Finish
  • RAB ALEDXL5TWMNB/480 Type V LED Area Light – 300W-385W Selectable – 4000K – 39482-48439 Lumens – 480V – Wall Mount – Black Finish
  • RAB ALEDXL5TWMNB/480 Type V LED Area Light – 300W-385W Selectable – 4000K – 39482-48439 Lumens – 480V – Wall Mount – Black Finish
  • RAB ALEDXL5TWMNB/480 Type V LED Area Light – 300W-385W Selectable – 4000K – 39482-48439 Lumens – 480V – Wall Mount – Black Finish
  • RAB ALEDXL5TWMNB/480 Type V LED Area Light – 300W-385W Selectable – 4000K – 39482-48439 Lumens – 480V – Wall Mount – Black Finish
  • RAB ALEDXL5TWMNB/480 Type V LED Area Light – 300W-385W Selectable – 4000K – 39482-48439 Lumens – 480V – Wall Mount – Black Finish
  • RAB ALEDXL5TWMNB/480 Type V LED Area Light – 300W-385W Selectable – 4000K – 39482-48439 Lumens – 480V – Wall Mount – Black Finish
RAB ALEDXL5TWMNB/480 Type V LED Area Light – 300W-385W Selectable – 4000K – 39482-48439 Lumens – 480V – Wall Mount – Black Finish

RAB ALEDXL5TWMNB/480 Type V LED Area Light – 300W-385W Selectable – 4000K – 39482-48439 Lumens – 480V – Wall Mount – Black Finish

UL Certified DLC Premium Listed Wattage Adjustable Type V Distribution IP66 Rating 0-10V Dimmable 10kV Surge Protection Wet Location Rated 80+ CRI 480V 100000 Rated Hours

Description

The RAB Lighting ALEDXL5TWMNB/480 LED wall-mount area light is configured with selectable 300W-385W operation, 39482-48439 lumens, and 4000K color temperature. It features Type V optics, wall mounting, and 480V operation in a black housing. This area light is suited for open parking and general area-lighting layouts that require broad, symmetrical coverage and is designed for perimeter installation on a compatible wall-mounted arm or bracket. Selectable wattage allows light output to be adjusted during installation to meet project requirements.

Specifications

  • Vendor: RAB Lighting
  • MPN: ALEDXL5TWMNB/480
  • Product Type: Area Light
  • Wattage: 300W, 345W, 385W
  • Input Voltage: 480V
  • Lumens: 39482-48439
  • CCT: 4000K
  • CRI: 80+
  • Light Distribution: Type V
  • Dimming: 0-10V
  • Features: Wattage Selectable, CCT Selectable
  • Certifications: UL
  • DLC Rating: DLC Premium
  • DLC Product ID: S-78XG46
  • IP Rating: IP66
  • Location Rating: Wet
  • Mounting Type: Wall
  • Mounting Height: 25–35 ft
  • Housing: Die-Cast Aluminum
  • Lens: Polycarbonate
  • Operating Temperature: -40°F to 104°F (-40°C to 40°C)
  • Weight: 36.3 lbs
  • Finish: Black
  • Dimensions: 32.5"L x 19"W x 5"H
  • Rated Hours: 100000
  • Warranty: 10 Years
  • Applications: Parking Lots, Roadways, Commercial Campuses, Distribution Centers, Industrial Facilities
