RAB FHID-20-EX39-850 Filament HID LED Lamp – ED23.5 – 20W – 5000K – EX39 Mogul Base – CRI80 – 120-277V – 3600 Lumens

RAB FHID-20-EX39-850 Filament HID LED Lamp – ED23.5 – 20W – 5000K – EX39 Mogul Base – CRI80 – 120-277V – 3600 Lumens

$22.00
$22.00
Skip to product information
RAB FHID-20-EX39-850 Filament HID LED Lamp – ED23.5 – 20W – 5000K – EX39 Mogul Base – CRI80 – 120-277V – 3600 Lumens
  • RAB FHID-20-EX39-850 Filament HID LED Lamp – ED23.5 – 20W – 5000K – EX39 Mogul Base – CRI80 – 120-277V – 3600 Lumens
  • RAB FHID-20-EX39-850 Filament HID LED Lamp – ED23.5 – 20W – 5000K – EX39 Mogul Base – CRI80 – 120-277V – 3600 Lumens
  • RAB FHID-20-EX39-850 Filament HID LED Lamp – ED23.5 – 20W – 5000K – EX39 Mogul Base – CRI80 – 120-277V – 3600 Lumens
  • RAB FHID-20-EX39-850 Filament HID LED Lamp – ED23.5 – 20W – 5000K – EX39 Mogul Base – CRI80 – 120-277V – 3600 Lumens
  • RAB FHID-20-EX39-850 Filament HID LED Lamp – ED23.5 – 20W – 5000K – EX39 Mogul Base – CRI80 – 120-277V – 3600 Lumens
  • RAB FHID-20-EX39-850 Filament HID LED Lamp – ED23.5 – 20W – 5000K – EX39 Mogul Base – CRI80 – 120-277V – 3600 Lumens
  • RAB FHID-20-EX39-850 Filament HID LED Lamp – ED23.5 – 20W – 5000K – EX39 Mogul Base – CRI80 – 120-277V – 3600 Lumens
  • RAB FHID-20-EX39-850 Filament HID LED Lamp – ED23.5 – 20W – 5000K – EX39 Mogul Base – CRI80 – 120-277V – 3600 Lumens
  • RAB FHID-20-EX39-850 Filament HID LED Lamp – ED23.5 – 20W – 5000K – EX39 Mogul Base – CRI80 – 120-277V – 3600 Lumens
  • RAB FHID-20-EX39-850 Filament HID LED Lamp – ED23.5 – 20W – 5000K – EX39 Mogul Base – CRI80 – 120-277V – 3600 Lumens
  • RAB FHID-20-EX39-850 Filament HID LED Lamp – ED23.5 – 20W – 5000K – EX39 Mogul Base – CRI80 – 120-277V – 3600 Lumens
  • RAB FHID-20-EX39-850 Filament HID LED Lamp – ED23.5 – 20W – 5000K – EX39 Mogul Base – CRI80 – 120-277V – 3600 Lumens
RAB FHID-20-EX39-850 Filament HID LED Lamp – ED23.5 – 20W – 5000K – EX39 Mogul Base – CRI80 – 120-277V – 3600 Lumens

RAB FHID-20-EX39-850 Filament HID LED Lamp – ED23.5 – 20W – 5000K – EX39 Mogul Base – CRI80 – 120-277V – 3600 Lumens

ETL Listed IP54 Rating TRIAC Dimmable Wet Location Rated 80+ CRI 120-277V 50000 Rated Hours

Description

The RAB Lighting FHID-20-EX39-850 filament HID LED lamp delivers 3,600 lumens at 20W with a 5000K color temperature, an EX39 mogul base, CRI80, and 120-277V input. Efficient LED technology provides dependable performance while reducing maintenance requirements.

Specifications

  • Vendor: RAB Lighting
  • MPN: FHID-20-EX39-850
  • UPC: 192552045926
  • Product Type: LED Glass Filament HID Bulb
  • Wattage: 20W
  • Wiring Type: Type B
  • Input Voltage: 120-277V
  • Power Factor: 0.9+
  • Surge Protection: 4 kV
  • Lumens: 3600
  • CCT: 5000K
  • CRI: 80+
  • Lamp Shape: ED23.5
  • Lamp Base: Mogul EX39
  • Equivalent: 70W HID
  • Beam Angle: 360°
  • Dimming: TRIAC
  • Certifications: ETL, FCC, RoHS
  • IP Rating: IP54
  • Location Rating: Wet
  • Lens: Glass
  • Lens Color: Clear
  • Operating Temperature: -22°F to 113 °F (-30 °C to 45 °C)
  • Weight: 0.37 lbs
  • Dimensions: 7.75"L x 2.9375"D
  • Rated Hours: 50000
  • Warranty: 5 Years
  • Applications: Parking Lots, Roadways, Warehouses, Industrial Facilities, Commercial Campuses
